Festool OF1010E(B)Q 1/4" Plunge Router

Description

Features

Light weight and one-handed operation
MMC electronics for adaptation to the working material and temperature monitoring
Routing depth adjustment to 1/10 mm
Spindle stop for easy cutter changes
Chip extractor integratedin the router table for efficient dust extraction
Main applications Rounding, chamfering, rebating and profiling edges Recessing metal fittings Grooving rear panels, recessing dovetail batons or routing plasterboard with the guide system (edging technology) Producing rows of holes in cabinets using the hole series system LR 32 Fashioning wooden joints with the VS 600Technical data
Power consumption 1010 WIdle engine speed 10000-24000 min-1Collet 6-8 mm
Routing depth adjustment range 55 mm
Fine height adjustment range 8 mm
Connection Ø d/e 27 mm
Weight 2,7 kg Includes:Ø 1/4" collet (6,35 mm)Ø 8 mm clamping colletside stopguide rail adapterchip deflectoroperation toolsystainer carry case
Warranty

Features

Maximum flexibility thanks to flat housing for minimum wall distance• Even more precise thanks to angle setting with snap-in points and indentation (-1° and/or 47°)• Guide wedge for safer work and simple positioning in existing joint• Good view of scribe line and saw blade thanks to the new flush and moveable viewing window• Improved dust extraction thanks to the new shape of the extraction duct• Simpler operation with the double cutting depth scale (with/without guide rail)• More benefits: splinterguard, Fast
Fix, play adjustment without the need for tools, quick brake, etc.Main applications• Precise circular in materials up to 55 mm thick• Cutting interior doors to length using guide rail and circular saw• Manufacturing expansion joints in parquet flooring and false joints• Cutting chipboard to size• Cutting and processingplasterboard

Specification

Power consumption 1200 WIdle engine speed 2000-5200 min-1Saw blade diameter 160 mm
Inclination -1 / +47 °Cutting depth 0-55 mm
Cutting depth at 45 degrees 0-43 mm
Cutting depth at 45°/90° 0-43/0-55 mm
Connection Ø d/e 27/36 mm
Weight 4,5 kg
