DeWALT DW745RS Portable Table Saw

DeWALT DW745RS Portable Table Saw

Voltage
Please select from the options above.
Quantity
-
+

Fast Delivery


Features


22 kg unit weight and optimised footprint make this the most portable saw in its class

Steel roll cage protects saw against jobsite drops and impacts

Rack and pinion fence system, front and rear fence lock and large, clear scales combine to give an extremely accurate and easy to use saw

Powerful 1850 Watt motor (1300w for 110v version) for high performance in all applications

Fence system provides 610 mm of rip capacity in a portable design for cutting large sheet materials to size

Cast table top design ensures accuracy and precision

Overload protection system ensures powerful performance in hard, wet or frozen woods

Quick bevel lock with largescale for easy, accurate adjustment

Large Heavy-Duty wheels designed to easily roll over steps, kerbs, and jobsite debris

Folding legs with quick release levers which retract under the stand in a few seconds for easy and quick transport

Lightweight aluminium construction stand which improves the portability

Heavy-Duty kick stand allows the stand to balance upright for mobility and storage

Retractable soft grip handle slides outallowing the user to pull the saw behind him comfortably

Stand design allows portability when the table saw is attached to the stand which increases productivity


Specification


Power Input 1700 Watts (1300w for 110v version)
Blade Speed 3800 rpm
Blade Diameter 250 mm
Blade Bore 30 mm
Bevel Capacity -3 to 48°
Max. Ripping Capacity [right] 610 mm
Max. Ripping Capacity [left] 315 mm
Max. Depth of Cut at 90º 77 mm
Max. Depth of Cut at 45º 57 mm
Table Size 630 x 570 mm
Weight 22 kg
Depth 742 mm
Length 577 mm
Height 425 mm


Standard Equipment


Heavy Duty Rolling Saw Workstation
Universal Brackets to attach most Table saws
24 tooth SERIES 30 saw blade
Mitre fence
2 blade spanners
Parallel fence
Dust port reducer
Push stick


Warranty





1 year warranty extended to 3 years with a MyDeWalt registration (within 4 weeks of purchase)
