Features

Easy handling with horizontal and vertical self-levelling
Easy to operate thanks to one button per function and self-explanatory display
Easy to setup in both the horizontal and vertical modes due to the automatic self-levelling of 8% (+-5degrees)
The shock warning function, which can be switched on and off, prevents levelling errors in the event of shocks or vibrations

Specification

Laser diode 635 nm, < 1 mW
Laser class 3R
Working range with receiver 300 m (Diameter)
Levelling accuracy ± 0.1 mm/m
Self-levelling range ±?5°
Dust and splash protection IP 54
Rotation speed 150, 300, 600 rpm
Power supply 1 x 9 V 6LR61 Block
1 x 1.5 V LR6 (AA)
2 x 1.5 V LR6 (D)
Operating time, max. Rechargeable batteries (NiMH) 30 h
Alkaline 50 h
Tripod thread 5/8"
Weight, approx. 1,8 kg
Length 190 mm
Width 180 mm
Height 170 mm

Standard Equipment

Laser Receiver LR 1 Professional (0 601 015 400)
Holder also available separately as an accessory (ET no. 1 608 M00 05A)
Remote Control RC 1 Professional (0 601 069 900)
Universal Mount WM 4 Professional (0 601 092 400)
1 NiMH battery (ET no. 1 608 M00 056)
Charger set with adapter (ET no. 1 608 M00 05E)
Battery housing
2 x 1.2 V HR20 (D) (9 Ah)
2 x 1.5 V LR20 (D)
Laser target (red) (ET no. 1 608 M00 05C)
Laser viewing glasses (red) (ET no. 1 608 M00 05B)
Building Tripod BT 300 HD Professional (0 601 091 400)
Cut & Fill Rod GR 240 Professional (0 601 094 100)
Carrying case (ET no. 1 608 M00 05F)
