Features

The classic pull saw design improved and updated for the modern user
New 1800 Watt motor for powerful cutting in all materials
Dust extraction specifically designed to meet the needs of the professional user in heavy use applications, protection from airborn dust particles minimises health risk over long periods
The base and fence have been machined to meet the accuracy requirements of the most demanding applications
New head lock function allows the head to be fixed, restricting the traverse function for trim applications and ease of transportation
Integrated positive mitre stops at 15°, 22.5°, 30°, 45°, quick release mitre mechanism up to 50°
Sliding left hand fence with measuring scale for improved material support and management
Compact internal rail design for huge cutting capacity in a highly transportable format

Specification

Power Input 1800 Watts
Power Output 1100 Watts
Blade Speed 6300 rpm
Blade Diameter 216 mm
Blade Bore 30 mm
Bevel Capacity 48 °
Mitre Capacity [right/left] 50/50 °
Cutting Capacity at 90°/90° (W x H) 265 x 62 mm
Cutting Capacity at 90°/90° (W x H) 270 x 60 mm
Cutting Capacity at 45°/90° (W x H) 189 x 62 mm
Cutting Capacity at 45°/90° (W x H) 190 x 60 mm
Cutting Capacity at 90°/45° (W x H) 173 x 62 mm
Cutting Capacity at 90°/45° (W x H) 270 x 48 mm
Max. Cutting Capacity at 45°/45° 190x48 mm
Max. Depth of Cut [Saws] 80 mm
Weight 14.0 kg
Depth 550 mm
Length 490 mm
Height 590 mm

Standard Equipment

24 tooth saw blade
2 bench mounting bolts
Blade spanner

Warranty

30 Day No Risk Satisfaction Guarantee
1 year full warranty
1 year free service contract
