Features

Cam action mitre lock function makes mitre setting faster and easier allowing the user to quickly adjust angles between 0° - 60° left and 0° - 50° right
The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications
The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles. This provides maximum stability and accuracy.
Linear horizontal rails utilise bronze guides to provide maximum precision when cutting materials up to 320 mm wide
Quick release bevel setting provides accurate and simple setting of bevel angles up to 48° left and right
Compact and lightweight design characteristics deliver a saw with enormous capacity which is easy to transport around the jobsite
XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity

Specifications

Power Input 1675 Watts
Power Output 750 Watts
Blade Speed 4000 rpm
Blade Diameter 250 mm
Blade Bore 30 mm
Bevel Capacity 48/48 °
Mitre Capacity [right/left] 50/60 °
Cutting Capacity at 90°/90° (W x H) 302x88 mm
Cutting Capacity at 90°/90° (W x H) 320x76 mm
Cutting Capacity at 45°/90° (W x H) 213x88 mm
Cutting Capacity at 45°/90° (W x H) 226x76 mm
Cutting Capacity at 90°/45° (W x H) 302x58 mm
Cutting Capacity at 90°/45° (W x H) 320x50 mm
Max. Cutting Capacity at 45°/45° 226x50 mm
Max. Depth of Cut [Saws] 152 mm
Weight 23 kg
Depth 541 mm
Length 718 mm
Height 442 mm

Standard Equipment

60 tooth blade
Blade spanner
Dust bag

Warranty

1 year free service contract
1 year full warranty
30 Day No Risk Satisfaction Guarantee
