Features

22 kg unit weight and optimised footprint make this the most portable saw in its class
Steel roll cage protects saw against jobsite drops and impacts
Rack and pinion fence system, front and rear fence lock and large, clear scales combine to give an extremely accurate and easy to use saw
Powerful 1700 Watt motor for high performance in all applications
Fence system provides 410 mm of rip capacity in a portable design for cutting large sheet materials to size
Cast table top design ensures accuracy and precision
Overload protection system ensures powerful performance in hard, wet or frozen woods
Quick bevel lock with large scale for easy, accurate adjustments.

Specification

Power Input 1700 Watts
Power Output 1100 Watts
Blade Speed 3800 rpm
Blade Diameter 250 mm
Blade Bore 30 mm
Bevel Capacity -3 to 48 °
Max. Ripping Capacity [right] 410 mm
Max. Ripping Capacity [left] 315 mm
Max. Depth of Cut at 90º 77 mm
Max. Depth of Cut at 45º 57 mm
Table Size 630 x 570 mm
Weight 22 kg
Depth 742 mm
Length 577 mm
Height 425 mm

Standard Equipment

24 tooth SERIES 30® saw blade
Mitre fence
2 blade spanners
Parallel fence
Dust port reducer
Push stick
