Features

Handy tool for cut-outs of all kinds
Slim, narrow design for optimum handling
Swivel-mounted die plate for better manoeuvrability in corners
Easy-to-change cutting tools
Lockable die plate for straight cuts
Working to scribe mark and template easily possible
For interior cut-outs

Specification

Material that can be processed Steel up to 400 N/mm² at 2.0 mm
Cutting track width 6 mm
Pre-drilling for interior cutout 16 mm
Smallest radius 3 mm
Stroke rate, load 1.500 spm
Stroke rate at no load 2.400 spm
Weight without cable 2,0 kg
Length 275 mm
Height 127 mm
Maximum cut thicknesses
Steel up to 400 N/mm² 2,0 mm
Steel up to 600 N/mm² 1,4 mm
Steel up to 800 N/mm² 1,0 mm
Aluminium up to 200 N/mm² 2,5 mm
Electric specifications
Rated power input 500 W
Power output 270 W

Standard Equipment

Punch (2 608 639 013)
Die plate (2 608 639 900)
Allen key KW 2.5 (ET no. 1 907 950 003)

Warranty

click above logo for details and to register your warranty
please note to qualify for the 3 year warranty you must register your tool within 4 weeks of purchase date
