Features

The most compact solution for dust-free drilling
Integrated, removable dust extraction unit for clean, dust-free working
Convenient working even overhead due to particularly compact design
Core cutter adapter set for dust extraction when working with core cutters (up to 68 mm)
Retaining valves prevent dust escaping
Changeable micro-filter for cost-effective service
Easy, tool-free removal of the dust extraction unit enables you to also work without dust extraction module

Specification

Rated power input 710 W
Impact energy 0 -2,5 J
Impact rate at rated speed 0 -4.400 bpm
Rated speed 0 - 1.000 rpm
Toolholder SDS-plus
Drilling range
Drilling diameter in concrete with hammer drill bits 4 -23 mm
Optimum range of applications in concrete with hammer drill bits 4-12 mm
Drilling diameter in concrete with dust extraction unit 4 - 16 mm
Max. drilling diameter in masonry with core cutters 68 mm
Max. drilling diameter in steel 13 mm
Max. drilling diameter in wood 32 mm

Functions

Forward/reverse operation
Electronic
Overload clutch
Dust extraction

Standard Equipment

Carrying case
Auxiliary handle (ET no. 1 619 P06 104)
Dust extraction unit
5 seal rings (ET no. 1 619 P06 107)

Warranty

click above logo for details and to register your warranty
please note to qualify for the 3 year warranty you must register your tool within 4 weeks of purchase date
